KVH C3



KVH C3







船载卫星天线KVH   C3:

Planning to cruise through US waters?




Intellian i6/i6P Specification

Physical

Dimensions(diameter x height)尺寸(直径×高度)

70 x 72 cm (27.5"x 28.3") 82× 37厘米

Weight重量

20 kg ( 44 lbs) 15公斤

Antenna Dish天线碟

60 cm (23.6") 45厘米

Environmental 环境

Operating Temp.温度。

-15˚C to +55˚C (+5˚F to +131˚F) -35 ˚ C--75 ˚c

Performance 性能

Frequency频率

Ku-Band(10.7 ~ 12.75 GHz) Ku波段( 10.7 〜 12.75千兆赫)

Minimum EIRPEIRP

47 dBW 50 dBW

Azimuth Range方位角范围

680˚ 680 ˚

Elevation Range俯仰范围

+5˚ to +90˚ 5 ˚到90 ˚

Ship's Motion船舶的运动

Roll ±25˚ , Pitch ±15˚辊± 25 ˚ ,间距± 15 ˚ Roll ±25˚ , Pitch ±15˚

Roll & Pitch Response Rate轧辊及回应率

45˚ / second 45 ˚ /秒

Turn Rate转弯速率

45˚ / second 45 ˚ /秒

Repeatability重复性

0.1˚ 0.1 ˚

LNBLNB

Dual Output / Quad Output双输出/四输出

ACU (Antenna Control Unit) 天线控制单元

Dimensions尺寸

178 x 217 x 54 mm (7" x 8.5" x 2.1") 178 x 217 × 45毫米

Weight重量

1.2 kg (2.6 lbs) 1.2公斤

=

Power电力

Input : DC 9.0~30.0V (Typ. 30W, Max 50W)输入:直流9.0 〜 30.0V (30W , 大50瓦)
